If you are in
need of a drilling rig for your location
(On shore United States Drilling Projects)
Contact
chris.sanders@yahoo.com
drilling waiting list in USA is 6 months
as of August 2022 because of demand
(call us in advance to arrange a drilling project) (310)
970-2400
We have about 40 older pulling units and workover rigs available
made from USA Steel -not from China!
They are all comparable to a Cooper 350 or 550, or a Wilson 42
during peak season they will all be worth $1 million each
They can all pull pipe from about 10,000' - 20,000' feet
Can all drill from 4,000' - 10,000' feet depending on your skill level
If you have good credit and can prove a recent bank statement
capable of putting our crews to work,
starting at $500,000.00 then
contact us.
If you need help with Finance from a bank to put a Drilling Rig to
work, we
are here to help you,
create an account with our bank
Point Bank and get your account started for rig purchase.
This is the 1969 Wilson in action
in the video above.
The Colonel was pulling 2 7/8" tubing from 6,000' feet,
well flowed in 54,000 BBL from initial re work.
Eric Byron and Chris Sanders of
Sanders Drilling contact us for all of your drilling needs
If you are a land owner Lessee or Lessor and
want us to drill on your land
contact us if you are in these states: (Arkansas, Colorado,
Louisiana, New Mexico, Montana, North Dakota, Oklahoma, South
Dakota, or Texas)
CAT 3412 Diesel Engine w/ Air Starter, Radiator, Gauges, Air Clutch
Rotating Equipment
IDECO 175F 17-1/2 x 44 Rotary Table w/ Split Master
Bushing
NATIONAL IDEAL F Swivel
4-1/4 x 40L Square Kelly
VARCO Kelly Drive Rushing, Square Drive
Traveling Equipment
McKissick/WILSON 250-Ton Block/Hook Combination w/ (5) Sheaves,
1-1/8 Line
2-3/4 x Approx. 96 Elevator Links
7W x 25L Tandem Axle Toolpushers Trailer, Fully Furnished,
Skidded
8W x 20L Doghouse w/3L Porch Extension, Round Top, Knowledge Box,
Lockers, Bench Storage, Cabinets,
Parts Bins, Fluorescent Lights, Heater, Skidded
76W x 30L Change House w/ Flat Top, Lockers, Bench Storage,
Cabinets, Incandescent Lights. Heater, Skidded
Generators/Utility House
(2) LEROY SOMER SDMO Generator Sets, each p/b
JOHN DEERE 4.5 Liter Diesel Engine w/ Electric Starter, Radiator,
Gauges, Skidded
QUINCY 325 Air Compressor p/b Electric Motor, Air Receiver Tank AllAbove Mounted in 76W x 22L Utility House
w/Round Top, 3-Compartment Lubester, Incandescent Lights,
Skidded
Mud System
10W x 6H x 36L Mud Suction Tank w/(3) Compartments, Flat Bottom,
Internal Plumbing, (2) Mud
Hoppers, Side-Mounted Walkways, Stairs, Safety Rails, Skidded
10W x 5H x 43L Mud Shaker Tank w/ Extension, (3) Compartments,
Flat Bottom, Internal Plumbing, Side-
Mounted Walkways, Stairs, Safety Rails, skidded
DOUBLE LIFE Dual Screen, Single Vibrating Shale Shaker, p/b Electric
Motor
Water Tanks
8W x 8H x 20 L Water Tank w/ 3L Extension
210-Barrel Round Water Tank w/ Side Skid
Handling Tools
WEB
WILSON
Type B Rotary Tongs w/ Heads
BJ 5 BN Center Latch Drill Pipe Elevators
DU Long 5 Drill Pipe Slips
Mud Bucket
Auxiliarv Equipment
BEAR Weight Indicator w/ BEAR Bit Weight Indicator
SATELLITE Automatic Driller
DRILL-O-GRAPH Single-Pen Recorder
3ID x Approximately 55L Rotary Hose
(2) 10ID x 5L Suction Hoses w/ Pipe
(2) 2ID x 15L & Approx. 25L Vibrator Hoses
36H x 5W x 50L 2-Section Catwalk w/ Steps
(6) 30H x 7W x 34L Pipe Tubs
Manual Wireline Measuring Device
Approx. (4) Miscellaneous Drill Collar Subs
Rathole & Mousehole
Fluorescent & Incandescent Rig Lights w/Wiring
Approx. 3500 of 1-1/8 Drill Line
Drill String
(18) 6-1/2 x 2-1/4 Drill Collars
9500 5 Drill Pipe
Rig #3
Inventory - ACTIVE NOT FOR SALE
Bill had
rig three taken down and drilling that night.
Drawworks
S45A
Bethlehem
Drawworks with Twin Disc Clutches and Foster Catheads with Oil
Bath
Chains, Daytank
Engines
D343 CAT with 425 HP with 11.525 Twin Disc Torque Converter
Mast
Al
Hicks 105 H Cantilever Mast Derrick, 300,000# Static Hook Load
Substructure
8 Substructure with
Loading Ramp, Hand Rails, Tarp Rails, Tarps
Pump
NATIONAL C-250 Mud Pump, Air Chamber, Bolted Cylinder Head Caps,
OTECO 2 Shear Relief Valve, Suction Screen, OTECO 0-3000 PSI
Pressure Gauge, Drive Assembly. Master Skidded w/ Engine
Pump Power
CAT D353 Diesel Engine w/ Air Starter, Radiator, Gauges, Air
Clutch-Newly Rebuilt
D-3304PCT CAT 105 kw CAT Generator, D-3304PCT CAT 105 kw CAT
Generator w/New Control Panels in Light House, Air Compressor and
Electric Motors in Light House
Mud System
100 bbl. Premix Pit,
New Single Vibrating Shale Shaker, p/b Electric Motor
Water Tanks
300 bbl. Water Tank
Handling Tools & Auxiliary
Equipment
WEB WILSON Type B Rotary Tongs w/ Heads
4-1/2 B.J. Elevators
7 B.J. Elevators
Drill Collar Clamps
Drill Collar Slips
4-1/2 Drill Pipe Slips & Elevators
(9) Drill Collar Nubbings
(16) 6-1/4 Drill Collars
6500 4-1/2 Drill Pipe
(2) Sets of Pipe Racks
(4) Pipe Tubs
Lay Down Pipe Roller
Mud Bucket
Hand Tools: 24,36, etc.
BEAR Weight Indicator w/ BEAR Bit Weight Indicator-New
SATELLITE Automatic Driller
DRILL-O-GRAPH Two-Pen Recorder-Newly Rebuilt
Rotary Hose-New
Suction Hoses w/ Pipe
12x4-1/2 Vibrator Hose
4000 gallon Diesel Tank
Kelly Shuck
Mousehole Shuck
Derrick Stand
Drilling Line Stand
2500 - 1 Swedge Drilling Line-New
2-Section Catwalk w/ Steps
(4) Sets of Steps
Rathole & Mousehole
Tandem Derrick Bolster (Mobile) with Derrick Bolster (Mobile)
Rig #4
Inventory
Drawworks
TRI SERVICES Drawworks, 600HP
Compound
(2) CUMMINS C8 3 Diesel Engines. 300HP, Air Drillers Controls
Brake
PARMAC Auxiliary Hydomatic Brake
Engines
(2)
DETROIT
Diesel Engines, 475HP, Each w/Electric Starter, Radiator, Gauges,
Air Clutch
DETROITDiesel Engine w/ Electric Starter,
Radiator, Gauges
Pump
GARDNER
DENVER
PZ 8 Mud Pump
Pump Power
CAT 379 Diesel Engine, 600HP, Radiator, Gauges
Rotating Equipment
SKYTOP BREWSTER 17-1/2 Rotary Table
KING Swivel, 150 Ton
4-1/2 x 40
L Square Kelly
WEB
WILSON
Kelly Drive Bushing, Square Drive
Traveling Equipment
SOWA 150 Ton Block/Hook Combination w/Sheaves Grooved for 1-1/8
Drill Line, Complete w/ Sandline Reel, Cat Line, Tugger Line
Sheaves, 350,000lbs. Capacity 2-3/4 x 53 Elevator Link
8
x 30 Doghouse, Drillers Box, Tool Box and Electrical Outlets
8 x 25 Skidded Parts House
10 x 25 Skidded Parts House/Change House w Lockers
Generators/Utility House
(2) DELCO 280 KVA Generator Sets, Powered by
WAUKESHA
4 Cylinder 20HP 30KW Diesel Engine, Powered by
DETROIT
Diesel/DELCO 8V71 7L78,
150KW Diesel Engine
Mud System
Mud Suction Tank w/ (3) Compartments w/ 450 bbs. Capacity
(2)
MISSION
MAGNUM/DOUBLE. LIFE Mud Mixing
Pump 5 x 6, Powered by AC Motor, 5OHP
DOUBLE LIFE Desilter. 810 GPM
Water Tanks
500 Barrel Round Water Tank
Handling Tools
WOOLEY Type C Manual Tongs, 3-1/2 to 8
4-1/2 WTM Drill Pipe Elevators, 150 Ton Capacity
8 Drill Collar Elevators, 50 Ton Capacity
Auxiliary Equipment
BEAR Weight Indicator w/ BEAR Bit Weight Indicator
BEAR Automatic Driller
DRILL-O-GRAPH Double-Pen Recorder
3-1/2 x 60L Rotary Hose w/ 5,000 PSI
AC Hydraulic Wireline Measuring Device
Rathole & Mousehole
Approx. 3500 of 1-1/58 Drill Line
7
x 35 Pipe Baskets
Sure Shot Survey Tool
5 x 9 Skidded Day Fuel Tank
JOY Single Drum Air Hoist
CUMMINS 300KW Generator End
CUMMINS 300HP Drawworks Motor - Spare
These are some more rigs - with inventory listed below.
RIG # 1:
IDECO H-1000 (Ref#7101) 1000 hp BACK-IN RIG Manufactured 1996, Ideco
single drum w/22 Parmac, powered by (2) Cummins NTA 1150 (900 hp)
Allison 5860 transmission, Ideco 112 x 358,000# hydraulically
raised mast, 4 standpipe, Gardner Denver 250 ton Hydra hook/block
unitized, Ideco TL 200 ton swivel, 4-1/4 x 39 square kelly, Ideco
20-1/2 rotary, 300 ton substructure 14 x 24 floor space, 13 KB
measurement w/10/6 clear height and 40 long center tub with
V-Door, Ideco MM550 7-1/4 x 15 steel fluid end duplex mud pump with
Hydril K20 dampener w/(2) Detroit 8V71N (600 hp) wheel mounted,
Ideco MM550 7-1/4 x 15 steel fluid end w/Hydril K20 w/Cat 3408 (500
hp) wheel mounted, (2) 225 bbl steel pits with 7 compartments wheel
mounted, desander, Detroit powered 5 x 6 centrifugal pump, shale
shaker, Cameron 11 x 5000# annular, Shaffer 11 x 5000# double ram
and 80 gallon 3000# accumulator, (2) 130 kw generators w/NT 855
Cummins on trailer, doghouse 8 x 20 elevating doghouse w/8 x 13
change room, Wooley type B tongs, 5-1/2 11-3/4 casing tools, EKEL
13-3/8 casing tongs, hand tools and operating supplies, 13-5/8
5000# BOP stoack, 11 x 10,000# BOP stack, 11 x 3000/5000# rotating
head, (2) 360 bbl water tanks. Highly mobile active rig, in field
ready condition, designed for maximum more efficient and minimum
location size. ACTIVE Price: $3,410,000
$28,000.00 per day rental rate.
RIG # 2:
IDECO 725E WORKOVER/DRILL RIG (Ref#6575) 1000 hp diesel electric rig
with 400,000# hook/load, Modular platform certified for offshore
use, modular concept allows land use easily, Ideco 725E drawworks
(900 hp), Parkersburg V-80 brake, 900 hp Toshiba 900A DC electric
motor, (2) Caterpillar 3412TA diesel engines with (3) 600 kw
generators, Ideco 100 x 400,000# hydraulically raised and wireline
scoped mast, 400,000# substructure will fit up to 56 platform beam,
(2) Ideco T500 triplex mud pumps powered by Toshiba 900A DC motor,
(2) 5 x 8 centrifugal pumps, Ideco 275K rotary table 27-1/2, Ideco
UTB-265T shorty hook/block, Ideco 300 TL swivel, 250 bbl mud system
in substructure with Brandt degasser, centrifugal pump, IPS Model
1000 SCR System, 600 VAC, 3 phase, 60 cycle, 13-5/8 x 5,000#
Shaffer double ram BOP, 13-5/8 x 5,000# Shaffer single ram BOP.
13-5/8 x 5,000# Shaffer spherical BOP, Koomey Type 80 Accumulator
with 6 station 3000 psi
ACTIVE - DAY RATE $28,000.00 PER DAY
RIG # 3 & 4:
2 available;
IDECO H-44 (Ref#7100) 700 hp DRIVE IN RIG #3 Manufactured 1982,
Ideco single drum with 22 Parmac, powered by (2) Cat 3406 DITA (700
hp) w/Allison 5860 transmission, Ideco 108 x 268,000# hydraulically
raised mast, 4 standpipe, Ideco 160 ton UTB unitized hook/block,
Ideco TL 200 ton swivel, 4-1/4 x 39 square kelly, Ideco 20-1/2
rotary, mounted on 5 axle self-propelled carrier, Substructure 300
ton with 18 x 21 floor space, 14 KB measurement with 1010 clear
height, substructure and walk section are unitized for wheel
mobilization including hydraulic boom and pipe equipment, (2) Ideco
MM550 7-1/4 x 15 duplex with Hydril K20 dampener and (2) on each
pump Cummins NT855 (670 hp) mounted on wheels. (2) 225 bbl steel
pits with 7 compartments wheel mounted w/two cone desander,
desilter, Cummins powered 5 x 6 centrifugal pump, shale shaker.
Cameron 11 x 5000# annular, Cameron 11 x 5000# type U double ram
and 80 gallon accumulator, (3) 8 x 2-1/4 DC, (21) 6-1/2 x 2-1/4 DC
and 7000 of 4 FH Grade E drill pipe, crew change room, 65 kw
Detroit powered generator on trailer, doghouse 8 x 20 elevating
with 2500 gal diesel tank and 80 gal wash down tank, 500 bbl frac
tank, drill pipe and casing slip, tongs and all necessary handling
tools, sub. High mobile active rig in field condition designed for
maximum more efficiency and minimum location size (2 available).
ACTIVE Price: $2,200,000/EACH.
DAY RATE $25,000.00 - BOOK IN ADVANCE
We have 4 more IDECO H-44 SANDERS
ACTIVE that we are
manufacturing as of August 2022. RATE $25,000 RENTAL BOOK IN ADVANCE
RIG # 764:
IDECO H37 (Ref#7086) Manufactured 1982, extensively rebuilt and
winterized for Arctic conditions. Double drum, 12V71 GMC diesel
engine, Allison CLBT-5860 transmission, 107 x 224,000#
hydraulically raised and telescoped mast, mounted on Ideco 5 axle
carrier with hydraulic leveling jacks, 150 ton McKissick block with
BJ 150 hook, Ideco Tl-200 swivel, Ideco 17-1/2 rotary table, 4-1/2
x 27 kelly, kelly bushing, 10-16 H x 10 W x 20 L cantilever
250,000 lb telescoping substructure with mud boat, Gardner Denver
PAH BFC triplex mud pump with GM 8V71 and Allison 4460 transmission,
(2) 30L x 5H x 76W 400 bbl mud system with 8 x 6 centrifugal
pump and GM 6V71 and GM 6V71 diesel engine, mud jets, 4 x 5 shale
shaker, 11 x 5000# Cameron BOP, 11 x 5000# Hydrill annular BOP and
160 gallon accumulator, (2) Cat 3306 diesel engines with 135 kw
generator in house, Volcano 50 hp boiler in building, 10 x 44
fully equipped wellsite unit, handling tools, spare parts for one
year. All components are new or rebuilt with certifications. Rig is
fully winterized for Arctic conditions and ready for shipping. This
rig even fully meets Russian Gorst requirements and therefore can be
operated in Russia if so required. Price: $4,000,000 -
ACTIVE $30,000 - DAY RATE This Rig is active on location and is now not for sale.
RIG # 6:
DRECOMODULAR DRILLING RIG Manufactured 1992, removed from platform
1997, Dreco D1500UE drawworks, 1500 hp rotary, Varco BJ top drive
TSS 3C27X01 hoist capacity 500 tons, Dreco 6-50 block (400 tons),
Varco vertical pipehandler 3-1/2 to 6-5/8, racking board 170
stands capacity, 37.5 Dreco rotary table, Dreco 500 ton mast, 4
module substructure,
SOLD Price: $9,350,000
RIG # 7:
IDECO H-44-CSC BIR7585 (Ref#7967) Manufactured 1984, 9800 capacity,
750 hp, Ideco Hydrair H-44-CSC with Parmac V80 brake, (2) Cat
340-DITA diesel engines (750 hp), Ideco KM-117-358AH 117 x 358,000#
Kwiklift mast, 16 substructure (139 clear height), (2) 8-1/2 x
6-1/4 National 8-P-80 mud pumps, (1) 13-5/8 5000 LWS Shaffer
double gate BOP, (1) 13-5/8 5000 Hydril GK annular, (1) 120LS type
80 3000 psi Koomey accumulator, 3-1/8 5000 psi manifold with 3 CIW
choke manifold, Ideco SR-23E rotary table, Ideco 265 ton Shorty
traveling block with 1-1/8 drilling line, Ideco TL-200 swivel,
8500 of 4-1/2 OD Grade G 16.6 lbs/ft 4IF drill pipe, (22) 4-1/2 OD
Heavy-weight, (6) 8 drill collars with 6-5/8 Reg., (24) 6-1/2
drill collars with 4 IF conn., (2) DFE linear motion SCR-01 shale
shakers, Drilco mud gas separator, 750 bbl capacity mud tank, (2)
Cat 3406TA (250 kw) generators. DAY RATE $40,000 PER DAY RENTAL -
$40,000 setup
RIG # 8:
IDECO H2500 (Ref#9802) Depth capacity 23,000 (7000 meters) with 5
drill pipe, Ideco H2500 drawworks with Elmagco 7838 brake, Ideco
full view mast 143 x 750,000# with 12 lines, 23 x 705,000#
substructure, 9-1/2 engine substructure, 27-1/2 Ideco rotary
table, Ideco 480 ton hook and block, Ideco 500 ton swivel, (5) tank
976 bbls mud system, w/Brandt shale shaker, separator and Swaco
shaker, (2) tanks total 210 bbl water tanks, Koomey 35 accumulator.
DAY RATE $40,000 PER DAY RENTAL - $40,000 setup
We have made donations to these non profit
companies
